Stainless Steel 18 Spoke Set 1936 / 1952 WL

Stainless Steel 18 Spoke Set 1936 / 1952 WL

by V-TWIN MANUFACTURING
SKU 45-0783
$208.70 - $208.70
$208.70
$234.94
$234.94 - $234.94
$234.94

OEM No:

Stainless Steel spoke set for stock OE spoke pattern lacing. Kit includes 40 spoke nipples. 9 gauge diameter single stage spokes feature a natural finish and two sizes 21.5mm and 15.5 mm. Cross four on drum side and two on small hub diameter end. Nipples are stainless steel. *NOTE: We suggest using 22mm long nipples when lacing 45 Front drum wheels. *NOTE: If required longer nipples are available separately.

FITMENT

  • 1936 / 1952 WL

    • TECH NOTES

  • Suggested to use with #52-0945 Conventional and #52-0946 Replica 40 Spoke 18inch X 3.15inch Front Wheel Rims.
  • Required to use with #45-0922 40 Piece Spoke Nipple Set Stainless Steel if longer nipples are needed.
  • Suggested to use with #45-0927 Spoke 40 Piece Stainless Steel Nipple Set.
  • Information for lacing the 18inch 45inch wheel: Drum Side - Top cross 1 spoke head face down. Lower spoke cross 1 spoke head faces up.
  • Spook side - top spoke cross 4 clockwise. Lower spoke cross 4 counter clockwise. 11/16inch offset from drum flange to side of rim.

    • MEASURMENTS

  • Short Spoke Length: 6 inches
  • Long Spoke Length: 8-3/8 inches
  • Diameter: 3.5mm
  • Nipple Length: 19.50mm

    • ACCESSORY ITEMS

  • 52-0785
  • 52-0758
  • 45-0770

    • REPLACEMENT PARTS

  • 45-0697

    • Model Fitment
